Avid G3 160mm Brake Rotor – Consistent braking, even after 10 consecutive descents
On long descents, your rotors can overheat, causing brake pads to glaze over. This leads to unpredictable braking performance exactly when you need it most. The Avid G3 160mm rotor is engineered specifically for these demanding conditions, featuring heat-dissipating cut-outs and high-grade stainless steel that stands up to mud, rain, and abrasive wear year after year.
Note: This product is BRAND NEW and supplied with 6 Torx mounting bolts included. Please verify compatibility with your bike’s fork or frame before purchase (standard 6-bolt mounting, 44mm bolt circle diameter).
Why choose the Avid G3 160mm rotor? (Key benefits):
- Active heat dissipation — The G3 cut-out pattern increases surface area for better airflow, allowing the rotor to cool rapidly between braking zones and preventing brake fade on descents of 500m+
- Corrosion-resistant stainless steel — Designed to stay clean and uniform even after a full season of riding in wet and muddy conditions, with no premature wear or rust
- Lightweight at just 115g — Lighter than most 160mm rotors in its class, without compromising on structural rigidity
- Universal IS 6-bolt mounting — Fits any standard hub, including e-bikes, without the need for adapters or modifications
- Ready to install — Includes 6 T25 Torx bolts calibrated for a secure, play-free fit, so you don’t need to buy extra hardware
Performance and Details
The wavy, ventilated profile of the G3 rotor isn’t just for looks—it increases the surface area exposed to air by up to 30% compared to a solid disc, which directly translates to lower brake pad temperatures. The friction surface is precision-ground, ensuring uniform contact with your pads from the very first pull, with no vibrations or metallic squealing during the bedding-in period. The IS 6-bolt mounting system (44mm BCD) ensures compatibility with forks and hubs from Shimano, SRAM, Tektro, Magura, and most e-bike manufacturers.
| Parameter | Value / Detail |
|---|---|
| Brand | Avid |
| Rotor Model | G3 |
| Material | Stainless Steel |
| Colour | Silver |
| Outer Diameter | 160 mm |
| Number of mounting holes | 6 |
| Diagonal distance between holes | 44 mm |
| Distance between adjacent holes | 22 mm |
| Weight | 115 g |
| Mounting Type | Standard IS 6-bolt |
| Included Accessories | 6 x T25 Torx bolts |
| Compatibility | MTB, Trekking, City, E-Bike |
| Condition | NEW |
Package Contents
- 1x Avid G3 Brake Rotor – 160mm
- 6x T25 Torx mounting bolts
Frequently Asked Questions
Is this compatible with Shimano or SRAM hydraulic brakes?
Yes. The IS 6-bolt mount is a universal standard, working perfectly with hydraulic and mechanical calipers from Shimano, SRAM, Tektro, Magura, and others. Just ensure your caliper is compatible with a 160mm rotor diameter.
What tool do I need for installation?
The included bolts require a T25 Torx key. Tighten them in a cross pattern to 4–6 Nm. Most standard bicycle multi-tools include this size.
Does it work on an e-bike?
Yes. The heat dissipation design is built to handle the higher braking forces generated by the extra weight of an e-bike. Requirement: your hub must have a standard 6-bolt mount.
Do I need to bed in the pads after installation?
We recommend performing 10–15 progressive stops from medium speed to a complete halt. This ensures an even transfer of friction material onto the rotor, which optimizes braking power and eliminates initial noise.
