433MHz 2-Channel 1527 Learning Code Remote – Quick pairing, stable signal up to 100 metres
Need an extra remote for your automatic gate, RF relay, or wireless lighting system? This 1527 learning code model pairs with your compatible receiver in seconds—no complex configuration or software required.
Note: This remote control CANNOT clone other remotes. It functions exclusively by pairing directly with a compatible 1527-code receiver.
Why choose this model? (Key benefits):
- Up to 100m range in open spaces — perfect for large gardens, driveways, or warehouses without signal drop-off
- Universal 1527 code — compatible with most 433MHz RF receivers and relays on the market, including 1, 2, or 4-channel modules
- Ultra-compact design: 61 x 29 x 11mm — fits easily in your pocket, on a keyring, or in your car glovebox
- Low power consumption (≤12mA) — the included CR2016 batteries last for months, even with daily use
- Precise 433MHz ±0.2MHz signal — penetrates fences and thin walls without lag or missed commands
Performance and Specifications
The remote transmits on the 433MHz frequency with a deviation of only ±0.2MHz, ensuring a clean signal free from interference with other nearby wireless devices. With a minimum transmission power of 10mW, it effectively penetrates common obstacles like metal fences, partition walls, or garage doors. The 50–60KHz transmission rate ensures your button press is translated into an instant command with no perceptible lag.
| Parameter | Value / Detail |
|---|---|
| Frequency | 433 MHz |
| Encoding Method | 1527 Learning Code |
| Number of buttons / channels | 2 |
| Operating Voltage | DC 6V (2 x CR2016) |
| Operating Current | ≤12mA |
| Transmission Power | ≥10mW |
| Operating Distance | Up to 50m indoors / up to 100m in open space |
| Frequency Deviation | ±0.2MHz |
| Transmission Rate | 50–60KHz |
| Dimensions | 61 x 29 x 11 mm |
| Programming Type | Direct pairing with receiver |
Programming and Usage Instructions
- Power on your 433MHz RF receiver and enter ‘learning mode’—press and hold the receiver’s programming button until the LED lights up or flashes steadily.
- Firmly press the desired button on your remote (CH1 or CH2) once.
- The receiver’s LED will flash briefly or turn off, confirming that pairing was successful.
- Test immediately: press the programmed button again to ensure the relay switches.
- Repeat the process for the second channel if you wish to control two independent circuits.
- If pairing fails, clear the receiver’s memory according to the manufacturer’s instructions and restart the steps.
Package Contents
- 1 x 433MHz 2-Button RF Remote (1527 Code)
- 2 x CR2016 Batteries (pre-installed)
Frequently Asked Questions
Can this clone an existing remote?
No. It does not have a cloning function. It only works by direct pairing with a compatible 1527-code receiver—it cannot copy the signal from another remote.
Which receivers is it compatible with?
It is compatible with any 433MHz RF receiver or relay that supports the 1527 learning code, including 1, 2, and 4-channel modules. Please check your receiver’s specifications before purchasing.
How far does the signal reach?
Up to 100 metres in open spaces without obstacles. Indoors or in areas with thick walls, the typical range is approximately 50 metres.
Can I pair multiple remotes to the same receiver?
Yes. Most 433MHz 1527-code receivers can store dozens or even hundreds of remotes in their memory simultaneously—ideal if multiple family members require access.
How long do the batteries last?
The ≤12mA power draw is extremely efficient. With normal use (a few presses per day), the included CR2016 batteries will last for several months before needing replacement.
